PLANET LCG-300 on teollisuustason LoRaWAN-yhdyskäytävä, jokatarjoaa luotettavan yhteyden IoT-järjestelmille. LoRaWAN- protokollan tuella se auttaa yhdistämään langattoman LoRa- tiedonsiirtoverkon IP-verkkoon. LoRa-verkko mahdollistaa antureiden tietojen lähettämisen pitkien etäisyyksien päähänalhaisella virrankulutuksella. LCG-300 on täysin yhteensopiva LoRaWAN- protokollan kanssa ja tukee jopa 10km yhteyksiä 300 päätelaitteen kanssa.

Tekniset tiedot:
• Supports EU868
• 8x programmable parallel demodulation paths
• 2x DI/DO and 1 serial port (RS485) for Modbus applications
• SSL VPN and robust hybrid VPN (IPSec/PPTP/L2TP over IPSec)
• Stateful packet inspection (SPI) firewall and content filtering
• Blocks DoS/DDOS attack, port range forwarding
• Planet NMS controller system and CloudViewer app supported
• -45…+75C operating temperature; DIN-rail and fanless designs
• Hardware
– 4x 10/100/1000BASE-T RJ45 LAN ports, auto-negotiation, auto MDI/MDI-X
– 1x 10/100/1000BASE-T RJ45 WAN port, auto-negotiation, autoMDI/MDI-X
– 1x LoRa antenna
– 1x serial console port (RS485)
– 1x reset button
• LoRa Interface
– Supports IN865/EU868/RU864
– 8 programmable parallel demodulation paths
• IP Routing Feature
– Static route
– Dynamic route
– OSPF
• Firewall Security
– Cybersecurity
– Stateful Packet Inspection (SPI) firewall
– Blocks DoS/DDoS attack
– Content filtering
– MAC filtering and IP filtering
– NAT ALGs (Application Layer Gateway)
– Blocks SYN/ICMP flooding
• VPN Features
– IPSec/Remote Server (Net-to-Net, Host-to-Net), GRE, PPTP Server, L2TP Server, SSL Server/Client (Open VPN)
– Max. Connection Tunnel Entries: 60 VPN tunnels,
– Encryption methods: DES, 3DES, AES, AES-128/192/256
– Authentication methods: MD5, SHA-1, SHA-256, SHA-384, SHA-512
• Networking
– Outbound load balancing
– Failover for dual-WAN
– Static IP/PPPoE/DHCP client for WAN
– DHCP server/NTP client for LAN
– Protocols: TCP/IP, UDP, ARP, IPv4, IPv6
– Port forwarding; QoS; DMZ; IGMP; UPnP; SNMPv1, v2c, v3
– MAC address clone
– DDNS: PLANET DDNS, Easy DDNS, DynDNS and No-IP
• Others
– Setup wizard
– Dashboard for real-time system overview
– Supported access by HTTP or HTTPS
– Auto reboot
– PLANET NMS System and Smart Discovery Utility for deployment management
– Planet CloudViewer app for real-time monitoring
