PLANET IGS-1020PTF on teollisuuskäyttöön soveltuva 10- porttinen 10/100/1000Base-T (8x TX + 2x SFP) PoE Ethernet-kytkin laajennetulla käyttölämpötila-alueella sekä DIN-kiskokiinnityksellä.

Tekniset tiedot:
• 8x 10/100/1000BASE-T Gigabit Ethernet RJ45 ports with IEEE802.3af/at PoE+ Injector (Ports 1 to 8)
• 2x 100/1000BASE-X SFP slots for SFP transceiver type auto detection (Ports 9 to 10)
• Power over Ethernet
• Complies with IEEE 802.3at Power over Ethernet Plus, end- span PSE
• Backward compatible with IEEE 802.3af Power over Ethernet
• Up to 8 ports of IEEE 802.3af/802.3at devices powered
• 240W PoE budget
• Supports PoE power up to 30W for each PoE port
• Auto detects powered device (PD)
• Circuit protection prevents power interference between ports
• Remote power feeding up to 100 meters
• Industrial Case and Installation
• IP30 aluminum case
• DIN-rail and wall-mount designs
• 48..54VDC redundant power with reverse polarity protection
• Supports 6KVDC Ethernet ESD protection
• -40…+75C operating temperature
• Hardware-based 10/100Mbps (half/full duplex), 1000Mbps (full duplex), auto-negotiation and auto MDI/MDI-X
• Features Store-and-Forward mode with wire-speed filtering and forwarding rates
• IEEE 802.3x flow control for full duplex operation and back pressure for half duplex operation
• 8k MAC address table size
• 20Gbps switch fabric
• 9k jumbo frame
• Hardware-based DIP switch for ”Standard” and ”Extend” modeselection; the ”Extend” mode features 30W PoE transmission distance of 250m at speed of 10Mbps
• Automatic address learning and address aging
