PLANET SGS-6310-8P4X on hallittava ja pinottava Layer 3 – kytkin, jossa on 8x 10/100/1000BASE-T RJ45 PoE+-porttia ja neljä 1G/10GBASE-X SFP+ -liitännällä.

SGS-6310-8P4X sopii yritysverkkoihin, palveluntarjoajille jakampusympäristöihin, tarjoten 128 Gbit/s kytkentäkapasiteetin ja IPv4/IPv6-reitityksen. PoE+
-tuki mahdollistaa jopa 120W kokonaisviransyötön verkkolaitteille, kuten IP-kameroille ja tukiasemille.

Tuotepakkaus sisältää keskusyksikön, 19″ räkkikiinnitysraudat, DB9-RJ45 RS232 konsolikaapelin, verkkovirtajohdon ja pika-asennusoppaan.

Tekniset tiedot:
• 48x 10/100/1000BASE-T RJ45 copper ports
• 6x 10GBASE-SR/LR SFP+ slots, backward compatible with 1000BASE-SX/LX/BX SFP
• 1x RJ45 to DB9 console interface for switch basic management and setup
• Hardware Stacking
– Virtualized multiple SGS-6310 series stacked into one logical facility
– Connects with stack members via assigned 10G SFP+ interfaces
– Single IP address stack management, supporting up to 8 hardware units stacked together
– Stacking architecture supports redundant Ring mode
• IPv4 routing protocol supports RIPv1/v2 and OSPFv2
• IPv6 routing protocol supports RIPng and OSPFv3
• Routing interface provides per VLAN routing mode
• VRRPv1/v3 protocol for redundant routing deployment
• Supports route redistribution
• Supports hardware-based wire-speed VLAN routing
• Supports IPv4 IGMP v1/v2/v3, IGMP Snooping.
• Supports IGMP Fast Leave, MVR, IGMP filter
• Supports IPv6 MLD V1, MLD snooping
• 32K MAC address table, automatic source address learning and aging
• Supports VLAN
– IEEE 802.1Q tag-based VLAN
– Provider Bridging (VLAN Q-in-Q, IEEE 802.1ad) supported
– GVRP protocol for dynamic VLAN management
– Private VLAN Edge (PVE) supported
– MAC-based VLAN
– IP subnet-based VLAN
– Voice VLAN
• Supports Link Aggregation
– IEEE 802.3ad LACP (Link Aggregation Control Protocol)
– Static mode and LACP mode
– Maximum 64 trunk groups, up to 8 ports per trunk group
• Supports Spanning Tree Protocol
– STP, IEEE 802.1D (Classic Spanning Tree Protocol)
– RSTP, IEEE 802.1w (Rapid Spanning Tree Protocol)
– MSTP, IEEE 802.1s (Multiple Spanning Tree Protocol, spanning tree by VLAN)
– Supports BPDU & root guard
• Port mirroring to monitor the incoming or outgoing trafficon a particular port (one-to-one and many-to-one)
• Provides port mirror (many-to-1)
• Supports G.8032 ERPS (Ethernet Ring Protection Switching)
• Loop protection to avoid broadcast loops
• Link Layer Discovery Protocol (LLDP)
• Compatible with Cisco UDLD (uni-directional link detection) that monitors a link between two switches and blocks the ports on both ends of the link if the link fails at any point between the two devices
• 8 priority queues on all switch ports
• Support for strict priority and WRR (Weighted Round Robin) CoS policies
• Traffic classification
– IEEE 802.1p CoS/ToS
– IPv4/IPv6 DSCP
– Port-based WRR
• Strict priority and WRR CoS policies
• Supports IPv4 IGMP snooping v1, v2 and v3
• Supports IPv6 MLD v1 snooping
• Querier mode support
• Supports Multicast VLAN Register (MVR)
• Authentication
– IEEE 802.1x port-based network access authentication
– MAC-based network access authentication
– Built-in RADIUS client to cooperate with the RADIUS servers for IPv4 and IPv6
– RADIUS/TACACS+ login users access authentication
• Access Control List
– IP-based Access Control List (ACL)
– MAC-based Access Control List
– Time-based ACL
• DHCP snooping to filter distrusted DHCP messages
• IP Source Guard prevents IP spoofing attacks
• Dynamic ARP Inspection discards ARP packets with invalid MAC address to IP address binding
• IPv4 and IPv6 dual stack management
• Switch Management Interface
– Console/Telnet Command Line Interface
– HTTP Web switch management
– SNMP v1 and v2c switch management
– SSHv1/v2, TLSv1.2 and SNMPv3 secure access
• SNMP Management
– Four RMON groups 1, 2, 3, 9 (history, statistics, alarms and events)
• SNMP trap for interface Link Up and Link Down notification
• BOOTP and DHCP for IP address assignment
• System Maintenance
– Firmware upload/download via TFTP or HTTP Protocol for IPv4 and IPv6
• SNTP (Simple Network Time Protocol) for IPv4 and IPv6
• User privilege levels control
• Syslog server for IPv4 and IPv6
• Supports sFlow
• DHCP Functions
– DHCP Option82
– DHCP server/relay/client
• Network Diagnostic
– Supports ping, traceroute function for IPv4 and IPv6
– Supports DDM (Digital Diagnostic Monitor)
• Supports ISSU (In-service Software Upgrade) to guaranteeing non-stop user data transmission when the systemis upgraded.
• 100..240VAC Dual power redundant
• Active-active redundant power failure protection
• Backup of catastrophic power failure on one supply
• DRAM: 512MB
• Flash Memory: 16MB
• Dimensions (WxDxH): 440 x 279.8 x 44mm
• Weight: 4100g
• Power Consumption: 46.9W / 159.9BTU
• Power Requirements: Dual AC: 100..240V, 50/60Hz
• Fan: 2
• Operating: Temperature: 0..+50C
